2017 Chevrolet

• Frame
• Frame Type: Hydroformed

• Tires
• Rear Tire Size: P275/55R20
• Front Tire Size: P275/55R20
• Spare Tire Size: P265/70R17
• Rear Tire Order Code: QSS
• Front Tire Order Code: QSS
• Spare Tire Order Code: RC4
• Revolutions/Mile @ 45 mph - Rear: N/A
• Revolutions/Mile @ 45 mph - Front: N/A
• Revolutions/Mile @ 45 mph - Spare: N/A

• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Rear (Yes or ): Yes
• Disc - Front (Yes or ): Yes
• Rear Brake Rotor Diam x Thickness (in): 13.6 x 0.79
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.18

• Engine
• Engine Type: Gas V8
• Fuel System: Direct Injection
• Displacement: 5.3L/325
• Engine Oil Cooler: Yes
• Engine Order Code: L83
• SAE Net Torque @ RPM: 383 @ 4100
• SAE Net Horsepower @ RPM: 355 @ 5600

• Wheels
• Rear Wheel Material: Aluminum
• Front Wheel Material: Aluminum
• Rear Wheel Size (in): 20 x 9.0
• Spare Wheel Material: Steel
• Front Wheel Size (in): 20 x 9.0
• Spare Wheel Size (in): 17 x

• Mileage
• Fuel Economy Est-Combined (MPG): 18
• EPA Fuel Economy Est - Hwy (MPG): 22
• EPA Fuel Economy Est - City (MPG): 16

• Summary
• Body Code: E63
• Body Style: Double Cab Pickup
• Vehicle Name: Chevrolet Silverado 1500

• Steering
• Steering Type: Electric Rack & Pinion
• Steering Ratio (:1), On Center: 16.3
• Turning Diameter - Curb to Curb (ft): 46.9
• Turning Diameter - Wall to Wall (ft): N/A

• Emissions
• Tons/yr of CO2 Emissions @ 15K mi/year: 9.8

• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26

• Electrical
• Maximum Alternator Capacity (amps): 150
• Cold Cranking Amps @ 0° F (Primary): 720

• Suspension
• Axle Type - Rear: Semi-Floating
• Axle Type - Front: Independent
• Axle Ratio (:1) - Rear: 3.42
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Axle Ratio (:1) - Front: 3.42
• Suspension Type - Front: Independent
• Axle Capacity - Rear (lbs): 3950
• Axle Capacity - Front (lbs): 3950
• Spring Capacity - Rear (lbs): 3950
• Spring Capacity - Front (lbs): 3950
• Shock Absorber Diameter - Rear (mm): 35
• Shock Absorber Diameter - Front (mm): 46
• Stabilizer Bar Diameter - Front (in): 1.35

• Trailering
• Maximum Trailering Capacity (lbs): 10900
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1065
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 7100
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 710
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7100

• Transmission
• Drivetrain: Four Wheel Drive
• Trans Type: 6
• Trans Order Code: MYC
• Reverse Ratio (:1): 3.06
• Transfer Case Model: Magna MP1222/5/6
• Fifth Gear Ratio (:1): 0.85
• First Gear Ratio (:1): 4.03
• Sixth Gear Ratio (:1): 0.67
• Third Gear Ratio (:1): 1.53
• Fourth Gear Ratio (:1): 1.15
• Second Gear Ratio (:1): 2.36
• Trans Description Cont.: Automatic
• Transfer Case Gear Ratio (:1), Low: 2.72
• Transfer Case Gear Ratio (:1), High: 1.00

• Cooling System
• Total Cooling System Capacity (qts): 15.6

• Weight Information
• Gross Combined Wt Rating (lbs): 15000
• Gross Axle Wt Rating - Rear (lbs): 3950
• Gross Axle Wt Rating - Front (lbs): 3950
• Gross Vehicle Weight Rating Cap (lbs): 7100

• Exterior Dimensions
• Wheelbase (in): 143.5
• Cab to Axle (in): 41.50
• Height, Overall (in): 73.90
• Ground Clearance, Rear (in): 8.87
• Width, Max w/o mirrors (in): 80.0
• Ground Clearance, Front (in): 8.87
• Front Bumper to Back of Cab (in): 141.37
• Ground to Top of Load Floor (in): 34.5
• Length, Overall w/o rear bumper (in): 230.03

• Interior Dimensions
• Passenger Capacity: 6
• Front Hip Room (in): 60.73
• Front Leg Room (in): 45.27
• Front Head Room (in): 42.80
• Second Hip Room (in): 60.23
• Second Leg Room (in): 34.63
• Second Head Room (in): 38.67
• Front Shoulder Room (in): 65.93
• Second Shoulder Room (in): 65.80

• Cargo Area Dimensions
• Cargo Volume (ft³): 61.0
• Tailgate Width (in): 62.2
• Cargo Box (Area) Height (in): 21.10
• Cargo Box Width @ Floor (in): 64.9
• Cargo Box Length @ Floor (in): 78.87
• Cargo Box Width @ Wheelhousings (in): 51.03
